123/MINI-R-V-A plus

VAT excluded

The 123/MINI-R-V-A-plus is designed with the Mini enthusiast in mind. This ignition is ment for an A-plus engine.

Distributor cap
In stock

123/MINI-R-V-A-plus distributor for a Mini A-plus engine

The 123/MINI-R-V-A+ is designed with the Mini enthusiast in mind and is available for an A-plus engine.

Features of the 123/MINI-R-V-A-plus electronic ignition

The unit is laid out in such a way, that static timing can be done on TDC, by means of the built-in LED.
The unit offers 16 curves.

The unit also offers:
- Vacuum advance
- Automatic dwell
- Automatic power-cut after 1 second
- Gear shift retard

Please note about the 123/MINI-R-V-A-plus 123ignition

The A+ plus engines were made from circa 1980. Please make sure you'll need a A-plus version. For the old 'pre-A-plus' engines please order: 123/MINI-R-V.

If you want to tune your engine, we've got great news for you: this product is also available in a 123/TUNE+ version! Please read about the 123/TUNE+-4-R-V-MiniA+ here.

Please read the installation manual carefully. It contains more information about motor- and distributor numbers, static timing and the advance-curves, the specifications of the 123-ignition and a step-by-step description of the installation procedure. The installation manual also offers a comprehensive list, that links a curve-setting to a particular engine.

Coil and spark plugs

Although used coils all look alike, they should be viewed with suspicion since one cannot tell from the outside whether, and how often they were exposed to overheating in the past. Installing the 123ignition system will ensure that the coil will never be overheated again in future. We recommend the 123 Blue Coil.

Perhaps you'll also need new spark plugs? At 123ignitionshop we recently added the spark plugs most commonly used in combination with the 123ignitions we offer. See: the spark plugs list.

Data sheet

Direction of rotation
4,0 - 15,0 volts
500 - 8000 rpm
-30 to 100 Celsius
Stock or high energy coil, primary coil NOT below 1,0 ohm
Constant current, fully automatic
After 1 second current is switched off
Less than 0,5 degr. crankshaft
With vacuum, also works without when not connected.
Max. Advance
45 degr. crankshaft
red +6V of +12V, black - coil
